| SIZE | BOLT HOLE QTY. | BOLT HOLE DIA. (mm) | BOLT HOLE TYPE | P.C.D (mm) | C.B(mm) | OFFSET (mm) | THICKNESS (mm) | MAXLOAD(KG) | TIRE |
| 7.0-20 | 8 | 26 | 1*45 | 275 | 214 | 162 | 14 | 2800 | 9.00-20 |
| 8 | 26 | 1*45 | 275 | 221 | 162 | 14 | 2800 | ||
| 8 | 32.5 | SR22 | 285 | 221 | 162 | 14 | 2800 | ||
| 8 | 32.5 | SR22 | 275 | 214 | 162 | 14 | 2800 | ||
| 10 | 26 | 1*45 | 335 | 281 | 162 | 14 | 2800 | ||
| 10 | 26 | 1*45 | 285.75 | 220 | 162 | 14 | 2800 | ||
| 10 | 32.5 | SR22 | 285.75 | 222 | 162 | 14 | 2800 |
